The PRO INWELL 100 hydraulically operated drill rig is ideal for water well drilling application in rock formation. Thanks to its simple and compact design, excellent performance, high accessibility and reliability at afford cost in its class. The PRO INWELL 100 rig’s flexibility means it will be five piece construction (Mast, Tripod, Drill head, Feed gearbox and Power pack) and air compressor will be mounted on separate trolley or truck.Proven technology ensures easy maintenance and more productive. The rig can be customize as per customer requirement All the actuators are operated by proportional control valves

PRO INWELL 100

  • Drill rod handling 5 feet (1.5meter)
  • Drilling depth up to 330 feet (100 meters)
  • Drilling diameter 4.5 inch (114mm) -5 inch (127mm)
  • Pull up force 2500 kgf-3000 kgf
  • Drill head torque 80 kg.m
  • Air compressor 450 cfm/150 psi
  • Optional: Trolley mounted mud pump driven by diesel engine through mechanical drive for mud rotary drilling.
  • Drill head torque 215 kg.m
  • Air compressor 600 cfm/200 psi
  • Optional: Trolley mounted mud pump driven by diesel engine through mechanical drive for mud rotary drilling.
